F Series DCT Selector question
Posted: 21 Sep 2021, 20:49
by Tom
Hi,
You added the support for the DCT , just one question. Are the letters light up on the shifter?
Thanks
Tom
Re: F Series DCT Selector question
Posted: 21 Sep 2021, 23:50
by Luki
Yes all letters display
in tcu the selector FXX is set and tcu itself detects DCT or 8HP automatically
Re: F Series DCT Selector question
Posted: 22 Sep 2021, 15:19
by Tom
Great, thank you!
Re: F Series DCT Selector question
Posted: 24 Sep 2021, 13:26
by Mata
Is it possible to send CAN to shifter to turn on orange backlight, like in photo?
- 6D0E7365-3DF9-40C9-BB5D-4E4599EA85BA.jpeg (87.04 KiB) Viewed 4311 times
Re: F Series DCT Selector question
Posted: 27 Sep 2021, 20:44
by Luki
Yes, but I have not found what frame is responsible for this
Re: F Series DCT Selector question
Posted: 01 Oct 2021, 18:27
by e83 s54 8hp
Message is sent after light on and you need connect can2 to selector. I can actuate light with diagnostic tool.
Re: F Series DCT Selector question
Posted: 04 Oct 2021, 17:44
by Mata
Credit to a couple of guys on the Facebook group chat for the idea. I’ve modified the shifter internally to use a spare connector pin (pin 9) and jumped this via a 1k resistor to the brown wire (next tot the black wire) on the bundle leading from the pcb up to the shifter joystick. Wired pin 9 into +12v dashboard illumination which the orange backlight now follows.
Re: F Series DCT Selector question
Posted: 06 Oct 2021, 19:29
by e83 s54 8hp
Re: F Series DCT Selector question
Posted: 11 Dec 2021, 23:16
by honk3times
does tcu support aftermarket electronic shifter?
im coming here from htg after their tcu was not the greatest but i would like to use the electronic sequential style shifter i have from them since i cant return it.
since it doesnt have the ability to slide left to engage sport mode, can i just wire it to a switch and manually turn it off and on? thank you!
Re: F Series DCT Selector question
Posted: 14 Dec 2021, 13:21
by Luki
You can connect. You will switch between manual and automatic modes with the program switch
